I needed to replace the front brakes on a 1999 Chevy Prizm (Toyota Corolla). This works for 1998, 1999, 2000, 2001 and 2002 Prizm’s and Toyota Corollas- same design, same brakes and pads.

First step was to check prices and find that Undercar Specialty warehouse had the best prices-which they did. I called some other auto parts stores around Dayton and here are the prices they quoted me:

• Autozone: Ceramic pads - $38.99 / Rotors - $18.49 ea.
• John’s Auto Parts: Ceramic Pads - $46.62 / Rotors - $18.54 ea.
• Advanced Auto Parts: Ceramic Pads - $39.99 / Rotors - $24.96 ea.
• Genuine Auto Parts: Ceramic Pads - $51.71 / Rotors - $29.95 ea.
• Carquest: Ceramic Pads - $35-$60 / Rotors - $23.00 ea.

I headed to the warehouse at 1654 Springfield Street in Dayton to pick up a set of ceramic pads- I bought the “Undercar Certanium brake pads” (no relation to USW) for $37.93 and the rotors- 2 for $31.02 ($15.51 ea)

I also picked up some Permatex “Ceramic extreme brake parts lubricant” (it’s purple) for $12.94 (it’s way more than I’ll need- but, I want these brakes to feel like new).

And I got some brake cleaner (Braklean) for $2.26

You will also need the tools pictured below. (Jack not pictured) Basically, a 14mm and a 17mm socket, a screwdriver (or something to pry with) and the lugnut wrench from the tool kit- or an impact wrench.

First step is to jack up your car. If you don’t know how to do this, there are many resources on the web, such as this one.

I like to wear the rubber gloves to keep my hands clean-and not have to worry about caustic chemicals on my skin.

Once your car is jacked up pop off rim cover (if you have one) with a screw driver. Now you have access to the lug nuts on your wheel. My car had four. You can use a socket or an impact wrench to remove them. Many cars will come with a kit that has a small jack and the correct wrench to fit your wheels. Check your trunk under your spare tire. Once the wheel is off place it to the side.

With the wheel off you should be able to see the caliper. This is the cover that goes over the whole brake/rotor system. There should be a square window here so you can inspect your brakes. You will see a disk in the center, then the brake pad, then the brake pad backing, then the piston. Refer to the picture below to see where they all lay out on my Prism.

To loosen the pads, you need to separate them from the piston. Use a flat head screw driver to pry the piston back.

Sometimes this window is big enough so you don’t have remove the caliper to get at the brakes, but on my Prism, I needed to remove the caliper to get at the brakes. There are two bolts that I need to remove to get the caliper off. Use a 14mm socket wrench for this. One of my pads was broken in half and separated from the backing.

The next step is to remove the anchor. Mine was very rusty so I used 17mm socket with a long bar to get some good leverage.

Once these 2 bolts are removed, its time to get out the rotor. You should just have to pull it out. Set it aside.

Back to the caliper: Now pull the slides out of your caliper and apply the lubricant on them and on the spots that touch pads.

Unpack your new rotors and place them side by side on the ground and admire the new one.

Pick up the new one and place it back on the anchor where the old one was.

Reattach the rotor to the anchor with 2 lugnuts just to hold it in place- and slide your new brake pads into the caliper and make sure they are in contact with your new rotor. Most people think this is wrong, but the pads will keep continuous contact with the rotor.

Reattach the caliper, and look through the window. Note that these pads are thicker now and you can’t even see the backing.

Now remove the 2 lug nuts that were holding on the rotor- and put the wheel back on, with all 4 lugnuts.

Tighten the lugnuts- put the cover back on.

Congratulations, you are done! Now just pump the brakes a few times to get them primed and tight. They should feel loose for one or two pumps, and then tighten up. Take the car out on a slow easy run and make sure everything is working smoothly.

Now go have a party with all the money you just saved. Invoice #1232211
